MODEL 1
| Model No | SW 101A (EB 1 Phase & DG 1 Phase) |
| Technology | Microcontroller Based |
| EB Max Load | 30A |
| DG Max Load & Limit | As per Customer Specification |
| On Time & Trip Delay | 8 Seconds |
| Overload Locking | After 5 Tripping Cycles |
| Current Limit Point | 100 Watts to 10000 Watts |
| Working Voltage Range | 180 to 250 VAC |
| LED Indication | Mains, DG & Overload |
| Mounting & Cabinet | ABS, DIN Mounting |
| Product Warranty | 12 Months |
MODEL 2
| Model No | SW 101A (EB 1 Phase & DG 1 Phase) |
| Technology | Microcontroller Based |
| EB Max Load | 30A |
| DG Max Load & Limit | As per Customer Specification |
| On Time & Trip Delay | 8 Seconds |
| Overload Locking | After 5 Tripping Cycles |
| Current Limit Point | 100 Watts to 10000 Watts |
| Working Voltage Range | 180 to 250 VAC |
| LED Indication | Mains, DG & Overload |
| Mounting & Cabinet | ABS, DIN Mounting |
| Product Warranty | 12 Months |
